Shure ULXD4Q Quad-Channel Digital Wireless Receiver - G50 Band

Shure ULXD4Q G50 Band Quad-Channel Digital Wireless Receiver - Your Ultimate Sound Solution

Be part of the ULX-D wireless series! The Shure ULXD4Q offers 4 independent digital receivers in a tough, single-rack unit with an internal power supply. • Ideal for large venues and A/V installations. • With 4 digital audio channels in 1 rackspace. • Boasts a 64 MHz tuning range. • Expandable up to 60 channels. • Equipped with 2 Ethernet/Dante ports and 2 RF cascade ports. • Features audio summing. • Comes with secure AES-256 encryption.

Features:

• For Large Venues & A/V Installations
• 4 x Digital Audio Channels, 1 Rackspace
• 64 MHz Tuning Range
• Expandable up to 60 Channels
• 2 x Ethernet/Dante Ports
• 2 x RF Cascade Ports
• Audio Summing
• Secure AES-256 Encryption

Specifications:

• Number of RF Channel Frequencies: 2560
• Diversity: Antenna Diversity
• RF Frequency Band: G50 (470 to 534 MHz)
• RF Bandwidth: 64 MHz
• Frequency Step Size: 25 kHz
• RF Channel Scanning: Auto-Scan
• Max Operating Range: 328.1' / 100 m
• Max Transmitters per Band: 60
• OS Compatibility:
  • Windows 10 to 11
  • macOS 10.14 to 11.0
• Latency: < 2.9 ms
• Modulation: Proprietary
• Receiver:
  • Receiver Type: Rackmount
  • Mounting Options: Rackmount (with Included Hardware)
  • Rackmount Size: 1 RU (1/2 Rack)
  • Antenna: 2 x 1/2 Wave External, BNC (Rear-Mount)
  • Antenna Bias Voltage: 12 to 13 VDC, 150 mA (per Antenna)
  • Number of Audio Channels: 4
  • Audio I/O: 4 x XLR 3-Pin Male Balanced Output
  • Gain Range: -18 to +42 dB (1 dB Steps)
  • Pad: 30 dB
  • Audio Output Level:
    • XLR Outputs: +18 dBV (Line Level, Balanced)
    • XLR Output: -12 dBV (Mic Level)
  • Phantom Power Protection: On XLR Outputs
  • Frequency Response: 30 Hz to 20 kHz ±1 dB (Dependent on Mic)
  • Network I/O: 2 x RJ45 (1 Gb/s)
  • Network Protocols: DHCP, Dante, Manual IP
  • Impedance: XLR Output: 100 Ohms (Balanced)
  • Approximate RF Sensitivity: -98 dBm
  • Adjacent Channel Isolation: >70 dB
  • Spurious: Rejection (>80 dB)
  • AC/DC Power Adapter: 15 VDC at 600 mA (Included)
  • Power Requirements: AC/DC Power Adapter
  • AC Input Power: 100 to 240 VAC, 50 / 60 Hz at 0.32 A
  • Display & Indicators:
    • 1 x Backlit LCD (Battery Status, Channel, Group, Menu Navigation)
    • 2 x Multi-Segment LED (AF Level, Output Level, Peak)
  • Housing: Steel
  • Operating Temperature: 0 to 122°F / -17 to 50°C
  • Storage Temperature: -20 to 165°F / -28 to 73°C
  • Dimensions: 19 x 1.7 x 10.8' / 482 x 44 x 274 mm
  • Weight: 7.6 lb / 3.4 kg
• Packaging Info:
  • Package Weight: 12.3 lb
  • Box Dimensions (LxWxH): 27.5 x 17.5 x 4'

The Shure ULXD4Q is perfect for large venues and A/V installations. It's designed for professionals who need high-quality sound solutions. This receiver has 4 digital audio channels in 1 rackspace. It has a 64 MHz tuning range and can be expanded up to 60 channels. The dimensions are 19 x 1.7 x 10.8' / 482 x 44 x 274 mm and it weighs 7.6 lb / 3.4 kg. It comes with 2 Ethernet/Dante ports, 2 RF cascade ports, audio summing, and secure AES-256 encryption. It's compatible with Windows 10 to 11 and macOS 10.14 to 11.0.
