Shure ULXD4D Dual-Channel Digital Wireless Receiver - V50 Band

Shure ULXD4D V50 Band Dual-Channel Digital Wireless Receiver - Your Ultimate Sound Solution

Part of the ULX-D wireless series, the Shure ULXD4D packs 2 independent digital receivers into a rugged, single-rack unit with an internal power supply. Two Ethernet ports support Dante digital audio, and RF cascade ports let you distribute antenna signals to another receiver unit. Audio summing turns this receiver into a 2-channel mixer.

Features:

• • Ideal for large venues and A/V installations
• • 2 digital audio channels in 1 rackspace
• • Expandable up to 60 channels

Benefits:

• • Secure AES-256 encryption for peace of mind
• • 64 MHz tuning range for flexibility
• • Audio summing for seamless mixing

Specifications:

• Number of RF Channel Frequencies: 1680
• Diversity: Antenna Diversity
• RF Frequency Band: V50 (174 to 216 MHz)
• RF Bandwidth: 42 MHz
• Frequency Step Size: 25 kHz
• Max Operating Range: 328.1' / 100 m
• Max Transmitters per Band: 60
• Latency: < 2.9 ms
• Modulation: Proprietary
• Receiver:
  • Receiver Type: Tabletop
  • Mounting Options: Rackmount (with Included Hardware)
  • Rackmount Size: 1 RU (1/2 Rack)
  • Antenna: 2 x 1/2 Wave External, BNC (Rear-Mount)
  • Antenna Bias Voltage: 12 to 13 VDC, 150 mA (per Antenna)
  • Number of Audio Channels: 2
  • Audio I/O: 2 x XLR 3-Pin Male Balanced Output
  • Gain Range: -18 to +42 dB (1 dB Steps)
  • Pad: 30 dB
  • Audio Output Level:
    • XLR Outputs: +18 dBV (Line Level, Balanced)
    • XLR Output: -12 dBV (Mic Level)
  • Phantom Power Protection: On XLR Outputs
  • Frequency Response: 30 Hz to 20 kHz ±1 dB (Dependent on Mic)
  • Network I/O: 2 x RJ45 (1 Gb/s)
  • Network Protocols: DHCP, Dante, Manual IP
  • Impedance: XLR Output: 100 Ohms (Balanced)
  • Approximate RF Sensitivity: -98 dBm
  • Adjacent Channel Isolation: >70 dB
  • Spurious: Rejection (>80 dB)
  • Power Requirements: AC Input
  • AC Input Power: 100 to 240 VAC, 50 / 60 Hz at 0.32 A
  • Display & Indicators:
    • 1 x Backlit LCD (Battery Status, Channel, Group, Menu Navigation)
    • 2 x Multi-Segment LED (AF Level, Output Level, Peak)
  • Housing: Steel
  • Operating Temperature: 0 to 122°F / -17 to 50°C
  • Storage Temperature: -20 to 165°F / -28 to 73°C
  • Dimensions: 19 x 1.7 x 10.8' / 482 x 44 x 274 mm
  • Weight: 7.4 lb / 3.4 kg
• Packaging Info:
• Package Weight: 11.95 lb
• Box Dimensions (LxWxH): 27.5 x 17.5 x 3'

The Shure ULXD4D V50 Band Dual-Channel Digital Wireless Receiver is perfect for large venues and A/V installations. It has 2 digital audio channels in 1 rackspace and can be expanded up to 60 channels. With dimensions of 19 x 1.7 x 10.8' (482 x 44 x 274 mm) and a weight of 7.4 lb (3.4 kg), it's easy to install and use. Get yours today and experience top-notch sound quality!
