Soundcraft 5044496 Vi1-48 Digital Mixing Console

Soundcraft Vi1-48 Digital Mixing Console - The Ultimate Sound Solution

Are you a professional sound engineer looking for a powerful and versatile digital mixing console? Look no further! The Soundcraft 5044496 Vi1-48 Digital Mixing Console is here to revolutionize your audio experience.

• With 48 channels of analogue input and 27 analogue outputs, plus 6 digital inputs, 4 Stereo FX Returns and 6 digital outputs, this console offers a comprehensive range of connectivity options. Expandable to 64 channels with a stagebox, it provides the flexibility you need for any live event or recording session.

• The intuitive 22-inch widescreen Vistonics touch interface allows for easy and precise control, while the 16 motorized channel faders, 8 output/VCA faders, and 2 master faders provide smooth and accurate mixing.

• Incorporating FaderGlow, Lexicon effects, BSS graphic EQs, and channel dynamics, this console delivers exceptional sound quality and performance. Compatible with Vi series show files, it offers seamless integration across different Soundcraft consoles.

Features:

• Powerful 48-channel analogue input and 27-channel analogue output capabilities
• Expandable to 64 channels with a stagebox
• Intuitive 22-inch widescreen Vistonics touch interface for easy control
• 16 motorized channel faders, 8 output/VCA faders, and 2 master faders
• Incorporates FaderGlow, Lexicon effects, BSS graphic EQs, and channel dynamics
• Compatible with Vi series show files for seamless integration

Specifications:

• Frequency Response:
  • Local Mic input to Line output: +0/-1dB, 20 Hz - 20 kHz
  • AES/EBU In to AES/EBU Out: +0/-0.2dB, 20 Hz - 20 kHz
• T.H.D. & Noise, 22 Hz - 22 kHz:
  • Local Mic In (min gain) to Local Line Out: < 0.003% @ 1 kHz
  • Local Mic In (max gain) to Local Line Out: < 0.020% @ 1 kHz
• Mic Input E.I.N.: < -126 dBu (150 Ohm source)
  • 22 Hz - 22 kHz bandwidth, unweighted
• Residual Noise: -95 dBu
  • Local line output; no inputs routed, Mix fader @0dB
• CMRR: 80dB @ 1kHz, Local Mic input
• Sampling Frequency: 48 kHz
• Latency, Local Mic Input to Local Line output: < 2ms @ 48 kHz
• AES/EBU Input Sample Rate: 32 – 108 kHz (with SRC enabled)
• DSP Resolution: 40-bit floating point
• Internal Clock:
  • Accuracy: < +/- 50ppm
  • Jitter: < +/- 5ns
• External Sync: BNC Wordclock, AES/EBU sync in, Video sync in
• Input & Output Levels:
  • Mic Inputs: +28 dBu max
  • Line Inputs: +22 dBu max
  • Line Outputs: +22 dBu max
  • Nominal Operating Level: 0 dBu (-18dBFS)
• Input & Output Impedances:
  • Mic Inputs: 2.7 kOhms
  • All other analog Inputs: >10 kOhms
  • Line Ouptuts: < 75 Ohms
  • AES/EBU Outputs: 110 Ohms
• Oscillator: 20Hz to 20kHz/Pink/White Noise,variable level
• Channel HP Filter: 20 Hz - 600 Hz, 18dB per octave
• Channel LP Filter: 1 kHz - 20 kHz, 18dB per octave
• EQ (Inputs and Bus Outputs):
  • HF: 20 Hz - 20 kHz, +/-18dB, Q= 0.3-8.7 or shelving
  • Hi-Mid: 20 Hz - 20 kHz, +/-18dB, Q=0.3-8.7
  • Lo-Mid: 20 Hz - 20 kHz, +/-18dB, Q=0.3-8.7
  • LF: 20 Hz - 20 kHz, +/-18dB, Q= 0.3-8.7 or shelving
• Metering: Internal 11-segment LED bar graphs plus 4-segment gain reduction meters for all inputs and Outputs. Peak hold variable from 0-2s.
• Mains Voltage Operating Range: 90 - 264V, 47 - 63Hz, autoranging
• Mains Power Consumption, Control Surface: 100W
• Internal Mass Storage: 4GB Compact Flash Card

The Soundcraft Vi1-48 Digital Mixing Console is a must-have for professional sound engineers. Whether you're working on a live event or in a recording studio, this console offers the power and versatility you need. With its 48 channels of analogue input, 27 channels of analogue output, and additional digital inputs and outputs, it provides a comprehensive range of connectivity options. The intuitive touch interface and motorized faders make it easy to control, while the high-quality sound processing ensures exceptional audio performance. The console is suitable for use in a variety of settings, including concerts, theaters, and broadcast studios. It has a width of just over a metre and is designed to be compact and portable. The 22-inch widescreen Vistonics touch interface provides a clear and easy-to-use control panel, allowing you to quickly and accurately adjust the settings. The motorized channel faders, output/VCA faders, and master faders offer smooth and precise mixing, giving you complete control over your audio. The console also features a range of advanced features, such as FaderGlow, Lexicon effects, BSS graphic EQs, and channel dynamics, to enhance your audio quality. Compatible with Vi series show files, it allows for seamless integration across different Soundcraft consoles, making it a versatile choice for any sound engineer.
