Sennheiser EM-XSW 1-A Table Top Receiver
Unleash Your Voice! This all-in-one wireless system is a dream come true for singers and presenters.
• Exceptional Sound: Features renowned Sennheiser evolution microphone capsules for outstanding live sound.
• Easy Setup: Automatic frequency management and synchronization via remote channel make it a breeze.
• Wide Compatibility: Up to 10 compatible channels in a stable UHF band for seamless performance.
The XS Wireless 1 Vocal Set includes an intuitive stationary receiver, a vocal microphone, and a microphone clamp. It's perfect for live sound, whether you're on stage or presenting.
What's in the box - 1 receiver EM-XSW 1
- 1 handheld transmitter SKM 825-XSW
- 1 microphone clamp MZQ 1
- 1 power supply NT 12-5 CW
- 2 AA batteries
Features:
- Exceptional live sound with Sennheiser's renowned evolution microphone capsules (e825 or e835)
- Antenna-switching diversity reception for reliable signal
- Integrated antennas for a sleek design
- Automatic frequency management and synchronization via remote channel for effortless setup
- Selectable UHF frequencies within a large bandwidth for flexibility
- Up to 10 compatible channels for multiple users
Specifications:
- Dimensions: approx. 200 x 42 x 127 mm
- THD, total harmonic distortion: 0.9%
- Pick-up pattern: cardioid
- Signal-to-noise ratio: 103 dBA
- RF output power: 10 mW
- Switching bandwidth: up to 24 MHz
- Operating time: approx. 10 hrs
- Modulation: wideband FM
- Output voltage: 1/4' (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket (balanced): +12 dBu
- Housing: rugged ABS housing for durability
- Dynamic range: dynamic
- Frequency: 8 frequency banks, each with up to 10 factory-preset channels
- Frequency range: 548-572 MHz
- Sensitivity: < 3 V at 52 dB(A)rms S/N
- Squelch: adjustable from 3 dB V to 28 dB V (combined with pilot tone)
- Synchronization: 2.4 GHz, Low Power OQPSK (only active during synchronization)
- Input sensitivity: 1.5 mV / Pa
- Adjustment Range Transmitter: 0 to -30 dB, adjustable in 10 dB steps
- Audio adjustment range: 45 dB, adjustable in 5-dB steps
- Line / Mic level: 20 dB, switchable
- Temperature Range operation: 0°C to +40°C, storage: –20°C to +70°C
- Receiver Principle: double superheterodyne
- Diversity principle: Antenna switching diversity via internal antennas
Receivers
- Weight approx. 340g
- Power supply Receiver: 12 V DC nom. / 300 mA
- AF frequency response Receiver: 50 to 16,000 Hz (–3 dB)
Microphone
- Weight approx. 245g
- Power supply Microphone: 2 AA size batteries, 1.5 V
- AF frequency response SKM 825: 80-14,000 Hz
This Sennheiser EM-XSW 1-A XS Wireless Table Top Receiver is perfect for singers and presenters. It offers an easy-to-use all-in-one wireless solution. With dimensions of approx. 200 x 42 x 127 mm and a receiver weight of around 340g, it's compact and portable. The set comes with a handheld transmitter, microphone clamp, power supply, and 2 AA batteries. It features excellent live sound with renowned Sennheiser microphone capsules, automatic frequency management for easy setup, and up to 10 compatible channels in a stable UHF band.
