RCF F16-XR 16 Channel Mixer with FX and Recording

RCF F16-XR Professional 16-Channel Mixer with FX and Recording

Unleash your creativity with the RCF F16-XR! This powerful mixer offers a wealth of features designed to enhance your audio mixing experience. • 10 Mic preamp inputs and 4 mono line inputs provide versatile connectivity for microphones and line-level devices. • 4 Stereo line inputs allow you to connect stereo sources with ease. • PRO DSP FX onboard with 16 presets offer a wide range of effects to add depth and character to your mixes. Plus, enjoy stereo recording and playback via USB port, 6 single control compressors for precise audio shaping, and much more.

Features:

• 10 Mic preamp inputs, 4 mono line inputs
• 4 Stereo line inputs
• PRO DSP FX onboard with 16 presets
• Stereo recording and playback via USB port
• 6 single control compressors
• Balanced main output +28 dB (Stereo XLR + TRS)
• Two stereo output busses and 4 aux sends (2 pre, 1 pre/post, 1 post)
• 60 mm faders
• Internal universal power supply
• Designed and engineered in Italy

Specifications:

• Electrical specifications
  • Frequency Response: 20 Hz – 20 kHz
  • THD+N, 20dB gain, 0dBu out (% A-Weighted): <0,02% A-Weighted
  • Power supply: Internal
  • Voltage requirements: 100 V - 240 V
  • Power consumption (W): 30 W
• Inputs
  • Gain Range: 0 dB – -50 dB
  • Gain Selection: 20 dB – -30 dB
  • HI-Z Line Inputs Impedance (MOhm): 1 Mohm
  • HI-Z Line Inputs: 1
  • Input Noise Level (dBu A-Weighted): -124 dBu A-Weighted
  • Mic Inputs Impedance (KOhm): 14 kohm
  • Line: 8
  • Line Input Impedance (kOhm): 21 kohm
  • Low Cut: 80 Hz
  • Mic: 10
  • Phantom Power +48V: Yes
  • Stereo Line: 4
  • Stereo Line Gain Selection: 20 dB – -30 dB
  • Stereo Line Input Impedance: 14 kohm
• Outputs
  • Main MIX: 1
  • Control Room: Yes
  • FX Send: 1
  • AUX Send: 3
  • AUX output: 4
  • Group Out: 4
  • Phones: 1
• Outputs specifications
  • Main Out Level (dBu): 28 dBu
  • Aux Out Level (dBu): 28 dBu
  • Group Out Level (dBu): 28 dBu
  • Phones Out impedance (Ohm): 150 ohm
  • Phones Out Level (dBm): 10 dBm
• Compressors
  • RCF Compressors: n°6 Single Control Compressors on Channels 1 to 6
• EQ
  • Input Channels EQ: 1 Semi Parametric / 2 Shelving
  • Description:
    • High: +/-15 dB @ 10 kHz Shelving
    • Mid: +/-15 dB @ Freq. sel. from 100Hz to 8kHz - Bell
    • Low: +/-15 dB @ 100 Hz Shelving
• Auxiliary sends
  • AUX: 2 PRE / 1 PRE/POST
  • FX POST: 1
• Internal Effects
  • Send Effects: 1
• USB audio
  • Type: B
  • Play trk: 2
  • Rec trk: 2
  • Supported Sample Rate (kHz): 44.1, 48.0 kHz
• Other features
  • Footswitch: Yes
• Standard compliance
  • CE marking: Yes
• Physical specifications
  • Cabinet/Case Material: Metal
  • Color: Black
• Size
  • Depth: 406 mm / 15.98 inches
  • Height: 107 mm / 4.21 inches
  • Weight: 6.4 kg / 14.11 lbs
  • Width: 479 mm / 18.86 inches
• Shipping informations
  • Package Depth: 523 mm / 20.59 inches
  • Package Height: 150 mm / 5.91 inches
  • Package Weight: 7.4 kg / 16.31 lbs
  • Package Width: 453 mm / 17.83 inches

The RCF F16-XR is a professional 16-channel mixer designed for musicians, audio engineers, and content creators. With its versatile input options, including 10 mic preamp inputs, 4 mono line inputs, and 4 stereo line inputs, you can connect a variety of microphones, instruments, and audio devices. The mixer also features 16 PRO DSP internal presets, two stereo output busses, and 4 aux sends, allowing you to add depth and character to your mixes. Whether you're recording in the studio, performing live, or streaming online, the RCF F16-XR provides the tools you need to create professional-quality audio. Its compact size (406 mm deep, 107 mm high, 479 mm wide) and lightweight design (6.4 kg) make it easy to transport and set up wherever you need it.
