Shure Axient AD4D-DC Two-Channel Digital Wireless Receiver - A Band
  • Shure Axient AD4D-DC Two-Channel Digital Wireless Receiver - The Ultimate Choice for Professional Productions
  • Shure Axient AD4D-DC Two-Channel Digital Wireless Receiver - The Ultimate Choice for Professional Productions
  • Shure Axient AD4D-DC Two-Channel Digital Wireless Receiver - The Ultimate Choice for Professional Productions

Shure Axient AD4D-DC Two-Channel Digital Wireless Receiver - A Band

$3,896.00  $50.00
Save: 99% off

HURRY! This item is discontinued. Shop now for best selection.

In Stock

  • Credit Card
  • Free Shipping
  • Delivered 2-5 Business Days
  • BEST OFFERS
  • 100% Satisfaction Guarantee
  • FREE returns & exchanges every day

Product Description

Shure Axient AD4D-DC Two-Channel Digital Wireless Receiver - The Ultimate Choice for Professional Productions

The Shure AD4D-DC is a game-changer in the world of wireless receivers! It's a 2-channel wonder with a built-in DC power module, along with a cable and mounting accessories. This baby accepts DC power for use in broadcast production trucks and AC for power redundancy, so you never have to worry about running out of juice.

As part of the Axient Digital system, it delivers rock-solid signal stability and crystal-clear, transparent sound for professional productions that demand perfection. Every feature has been rigorously tested to ensure seamless, uninterrupted audio in high-profile events like televised live performances, award shows, and corporate events, on the Broadway stage, in secure government installations, and state-of-the-art meeting and training facilities.

Features:

  • • Ideal for major events and high-end installations
  • • Comes with a DC power module
  • • 2 x Digital Audio Channels, 1 Rackspace
  • • 166 MHz Ultrawide Tuning Range
  • • Expandable to 120+ Channels
  • • True Digital Diversity Reception
  • • 4 x Ethernet/Dante Ports
  • • XLR and AES3 Outputs
  • • RF Cascade Ports
  • • Secure AES-256 Encryption

Specifications:

  • • Number of RF Channel Frequencies: 6640
  • • Diversity: True Digital Diversity
  • • RF Frequency Band: A: 470 to 636 MHz
  • • RF Bandwidth: 166 MHz
  • • Frequency Step Size: 25 kHz
  • • RF Channel Scanning: Auto-Scan
  • • Max Operating Range: 328.1' / 100 m
  • • Max Transmitters per Band: 120
  • • Timecode Support: No
  • • Mobile App Compatible:
    • Yes: Android & iOS
    • App Name: ShurePlus Channels
    • Functionality: Remote Control
  • • OS Compatibility:
    • Windows 10 or Later
    • macOS 10.14 or Later
  • • Latency: 2 to 2.9 ms (Selectable)
  • • Modulation: Proprietary
  • • Receiver:
    • Receiver Type: Rackmount
    • Mounting Options: Rackmount (with Included Hardware)
    • Rackmount Size: 1 RU (Full Rack)
    • Antenna: 2 x 1/2 Wave External, BNC (Rear-Mount)
    • Antenna Bias Voltage: 12 to 13 VDC, 150 mA (per Antenna)
    • Number of Audio Channels: 2
    • Audio I/O:
      • 2 x XLR 3-Pin Male Balanced Output
      • 1 x XLR (AES3) 3-Pin Male Balanced Output
      • 2 x 1/4' TRS Female Balanced Output
      • 1 x 1/4' TRS Female Unbalanced Headphone Output
    • Gain Range: -18 to +42 dB (1 dB Steps)
    • Pad: 30 dB
    • Audio Output Level:
      • XLR Outputs: +18 dBV (Line Level)
      • XLR Outputs: -12 dBV (Mic Level)
      • 1/4' Outputs: +8 dBV
    • Frequency Response: 20 Hz to 20 kHz ±1 dB (Dependent on Mic)
    • Network I/O: 4 x RJ45 (1 Gb/s)
    • Network Protocols: DHCP, Dante, Manual IP
    • Word Clock I/O:
      • 1 x BNC Input
      • 1 x BNC Through
    • USB/Lightning Connectivity: None
    • Standalone Audio Interface Capable: No
    • Impedance: XLR Outputs: 100 Ohms (Balanced)
    • Approximate RF Sensitivity: -98 dBm
    • Adjacent Channel Isolation: >70 dB
    • Spurious: Rejection: >80 dB
    • Power Requirements: AC Input, DC Input
    • AC/DC Power Adapter: 10.9 to 14.8 VDC at 3.3 A (Included)
    • DC Input Power: 10.9 to 14.8 VDC at 3.3A
    • AC Input Power: 100 to 240 VAC, 50 / 60 Hz at 0.68 A
    • Display & Indicators: 1 x Backlit LCD (AF Level, Battery Status, Channel, Frequency, Menu Navigation, Sync)
    • Housing: Steel
    • Operating Temperature: 0 to 122°F / -18 to 50°C
    • Storage Temperature: -20 to 149°F / -29 to 65°C
    • Dimensions: 19 x 1.7 x 13.1' / 483 x 44 x 333 mm (without Mounting Hardware, Antennas)
    • Weight: 10.1 lb / 4.6 kg (without Antenna)
  • Packaging Info:
    • Package Weight: 14.685 lb
    • Box Dimensions (LxWxH): 22.9 x 17.6 x 3.2'


The Shure Axient AD4D-DC Two-Channel Digital Wireless Receiver is perfect for professional productions like televised live performances, award shows, and corporate events. It's great for those in the broadcast, stage, and event industries. With a 1 RU rackmount size, it's compact. Weighing 10.1 lb (without antenna), it's easy to handle. It has a 2-channel setup and comes with a built-in DC power module. The max operating range is 328.1' / 100 m, and it can be expanded to 120+ channels.
