L-Acoustics A15I-FOCUS 2-Way Passive 15-Inch 10-Degree Curved Medium Throw Line Source Speaker

L-Acoustics A15I-FOCUS: The Ultimate 15-Inch Passive Line Source Speaker for Medium Throw

Discover the A15i Focus, the installation version of the A15 Focus. It's designed for medium throw applications and offers identical sonic performance as its touring counterpart, with a sleeker design and streamlined mounting hardware for seamless integration.

• Tightly-controlled 10° coverage for powerful projection up to 45 m and an impressive 144 dB output.

• Panflex technology allows you to adapt directivity to the audience, ensuring exceptional frequency response stability.

• Versatile use: Combine with A15i Wide to form a vertical line source or use individually as a configurable point source for front fill or delay.

The A15i Focus provides the low frequency contour of a large concert system, and when paired with the KS21i subwoofer, it extends the bandwidth to 29 Hz. It's a discreet, powerful, and versatile solution with a wide range of install-specific accessories for theaters, houses of worship, clubs, convention centers, and sports venues.

SPECIFICATIONS

• Description
• 2-way passive constant curvature WST 10°, amplified by LA2Xi2 / LA4X / LA8 / LA12X
• Usable bandwidth (-10 dB)
• 41 Hz - 20 kHz ([A15])
• Maximum SPL[1],[2]
• 144 dB ([A15])
• Nominal directivity
• Enclosure: 10°
• L-Fins: 70° / 110° symmetric or 90° asymmetric
• Transducers
• LF: 1 × 15'' cone driver
• HF: 1 × 3'' diaphragm neodymium compression driver
• Acoustical load
• LF: bass-reflex, L-Vents
• HF: DOSC waveguide, L-Fins
• Nominal impedance
• 8 Ω
• Connectors
• 4-point terminal block with push-in connection
• Connector sealing plate with cable gland
• Rigging and handling
• external rigging kits
• M6 inserts for rigging plates and accessories
• M8 inserts for A-U15i
• Safety
• 1 DIN580-compatible M8 threaded insert
• Weight (net)
• 32 kg / 71 lb
• Cabinet
• Premium grade Baltic beech and birch plywood
• Front
• Coated steel grill
• Acoustically neutral 3D fabric
• Finish
• Dark grey brown Pantone 426 C
• Pure white RAL 9010
• Custom RAL code on special order
• IP
• IP55

[1] Peak level at 1 m under free field conditions using pink noise with crest factor 4 (preset specified in brackets).

[2] For Max SPL values using LA2Xi, refer to LA2Xi system specification sheet.

The L-Acoustics A15I-FOCUS is a 15-inch passive line source speaker designed for medium throw installation applications. It's great for large theaters, houses of worship, clubs, convention centers, and sports venues. With a 10° enclosure coverage, it can project up to 45 m with an output of 144 dB. It weighs 32 kg (71 lb) and has a usable bandwidth of 41 Hz - 20 kHz. The speaker features a sleek design, streamlined mounting hardware, and Panflex technology for adaptable directivity.
