JBL VTX-V25-II-CS Dual 15-Inch Line Array Speaker 3-Way 90-Degree Compression Style Rigging

JBL VTX-V25-II-CS Dual 15-Inch High-Performance Line Array Speaker

Discover the JBL VTX-V25-II-CS, a full-size 3-way high-directivity line array speaker that delivers exceptional sound quality. With a new 4th generation waveguide, it offers improved long throw performance and wavefront control. It's also an excellent power match for the Crown IT4x3500HD.

Features:

• • Revolutionary 4th Gen HF Waveguide for amazing performance
• • Compression suspension hardware available for added convenience
• • D2 Dual Diaphragm, Dual Voice Coil Compression Driver for outstanding sound

Specifications:

• System Type: Full Size 3-Way High Directivity Line Array Element with D2 Dual Drivers
• Components:
  • 2 x 2267H 15' Differential Drive LF
  • 4 x 2169H 8' Differential Drive MF
  • 3 x 2430K D2 Dual Driver
• Horizontal Coverage (-6 dB): 90 degrees nominal (300 - 16k Hz)
• Frequency Range (-10 dB): 35 - 18k Hz
• Nominal Section Impedances: 2 x 8 ohms LF, 8 ohms MF, 8 ohms HF
• Continuous Power Rating (Active Mode): 2 x 2000W LF, 1400W MF, 600W HF
• Dimensions (W x H x D): 1223 mm x 414 mm x 614 mm (48.2' x 16.3' x 24.2')
• Weight: 82.6 kg (182 lb)

The JBL VTX-V25-II-CS Dual 15-Inch High-Performance Line Array Speaker is perfect for large venues like concert halls and outdoor festivals. It's designed for professional sound engineers and event organizers. With dimensions of 1223 mm x 414 mm x 614 mm (48.2' x 16.3' x 24.2') and weighing 82.6 kg (182 lb), it's a powerful addition to any sound setup.
