Shure QLXD4-X52 Digital Wireless Receiver: Your Ultimate Audio Solution
Unleash crystal-clear sound with the Shure QLXD4-X52 Digital Wireless Receiver! Enjoy professional features, seamless setup, and top-notch performance. Here's why it's a must-have:
- • Immaculate 24-bit digital audio for a studio-quality experience
- • Efficient RF spectrum usage, ensuring interference-free sound
- • Ideal for presentations, music venues, and houses of worship
The QLXD4 combines automatic scanning, one-touch sync, and Ethernet networking for effortless setup. With features like AES 256-bit encryption and high-contrast LCD controls, it's the complete package.
Product Specifications
- General Specs
- Dimensions: 41 ¡Á 197 ¡Á 151 mm, H ¡Á W ¡Á D
- Weight: 777 g, without antennas
- Housing: Steel
- Power requirements: 12 V DC @ 0.4 A, supplied by external power supply (tip positive)
- RF Input
- Spurious Rejection: > 80 dB, typical
- Connector Type: BNC
- Impedance: 50 Ω
- Audio Output
- Gain Adjustment Range: -18 to +42 dB in 1 dB steps
- Configuration: 1/4' (6.35 mm): Impedance balanced (Tip = audio, Ring = no audio, Sleeve = ground) / XLR: Balanced (1 = ground, 2 = audio +, 3 = audio )
- Impedance: 1/4' (6.35 mm): 100 Ω (50 Ω Unbalanced) / XLR: 100 Ω
- Full Scale Output: 1/4' (6.35 mm): +12 dBV / XLR: LINE setting = +18 dBV, MIC setting = 12 dBV
- Mic/Line Switch: 30 dB pad
- Phantom Power: Protection 1/4' (6.35 mm): Yes / XLR: Yes
- Networking
- Network Interface: Single Port Ethernet 10/100 Mbps
- Network Addressing Capability: DHCP or Manual IP address
- Maximum Ethernet Cable Length: 100 m
The Shure QLXD4-X52 Digital Wireless Receiver is perfect for presentation spaces, music venues, and houses of worship. It offers professional features, streamlined setup, and top-notch performance. With dimensions of 41 ¡Á 197 ¡Á 151 mm and a weight of 777 g (without antennas), it's compact and easy to handle.
