Powerful EAW UXA4416 Amplifier for Unbeatable Sound
Fully Integrated Touring Systems
Get the most out of your sound system with the UXA4416. Its processing engine supports FIR filters for EAW's KF, SB, and MW loudspeakers. Ensure consistent, top-notch performance night after night.
Dependable Sound when it counts
Rely on the proven technology of UXA4416 amplifiers. Rugged electronics and support mean these amps will last for years, providing high-quality coverage for various applications.
The UXA4416 features a 96KHz 40-bit floating point processing engine and four 4000-watt amplifier channels. It has standard analog and AES digital inputs, plus primary and secondary Dante network connections for digital signal supply. Connect to EAW's Resolution 2 software for easy large system configuration and monitoring, or use the intuitive front panel touch screen interface.
Features:
- • 4 x 4000W of Class D amplification for powerful sound
- • 96kHz, 40-bit floating point DSP with EAW Greybox presets for advanced audio processing
- • Pairs seamlessly with EAW Professional Systems for a complete setup
- • 4.3″ touch screen display for easy, user-friendly control
- • Primary and Secondary Dante with 2x Gigabit Ethernet for uninterrupted showtime
- • Resolution software and network control for configuring, monitoring, and controlling large systems
- • Universal PFC power supply for reliable performance worldwide
Specifications:
- Amplifier Class: D
- Output Power (all channels driven):
- 4 x 4000W @ 2.7 ohms
- 4 x 2600W @ 4 ohms
- 4 x 1400W @ 8 ohms
- Frequency Response (-3dB): 20 Hz - 23 kHz
- Gain (linear mode @ 0 dB): 32 dB
- Total number of inputs: 8
- Line Inputs: 4
- Line Connectors: XLR
- Input Impedance: 9 kohm (unbalanced)
- Maximum input level: +24 dBU
- Digital inputs: 4
- Digital connectors: Ethercon, XLR
- Digital type: 4 AES/EBU, 8 DANTE
- Signal output number: 4 x AES
- Power output lines: 4 x NL4
- General Purpose Outputs (GPO): 3
- Digital Signal Processing: 40-bit floating point, 96 kHz
- EQ Filters: Peaking, HI/LO-shelving, HI-pass, LO-pass
- Advanced algorithms: Focusing, Beamwidth Matched Crossovers, DYNO
- Compressors: RMS limiter, dynamic compressor, power limiter, thermal compressor
- Delay: 0 - 4000 ms (each channel)
- Configuration: Front panel touch screen, EAW Resolution
- Speakers Presets: EAW Greybox Library
- Control and monitoring protocols: Primary/Secondary DANTE
- Network: 2 x Gigabit Ethernet
- Operating voltage: 90-240 V~ 50/60Hz
- Power consumption idle: 90W
- Power consumption max: 5800W
- Dimensions (HxWxD): 3.49'x18.98'x18.99'
The EAW UXA4416 Powered Amplifier is perfect for professional sound setups like tours, concerts, and large events. It's designed for sound engineers and technicians who demand top-notch performance. With dimensions of 3.49'x18.98'x18.99' and various power consumption levels, it's a reliable choice for delivering high-quality sound in different venues.
