Powerful EAW RS151 15-Inch Self-Powered Subwoofer
Get ready to experience mind-blowing sound with the RS Series! It offers EAW signature performance in a portable and lightweight wooden enclosure. Here's why it stands out:
- • Touring grade transducers for top-notch sound
- • EAW Focusing for crystal-clear clarity and accuracy
- • Rotatable MK inspired horn for precise pattern control
The series is designed around the latest HF and LF transducers. With features like EAW Focusing, it provides unmatched musical clarity and tonal accuracy. The unique, constant directivity HF horn enhances pattern control. The lightweight and durable wooden enclosure eliminates resonance and houses onboard bi-amplified electronics (1500W) with signature EAW DSP.
Applications:
- Houses of Worship
- Theatres, Auditoria and Performing Arts Centers
- Live Music Clubs
- Corporate AV Houses
- Live Production/Regional Rental Houses
- Dry Hire
Features:
- Leading-edge touring grade transducers
- EAW Focusing for unmatched clarity and accuracy
- Rotatable MK inspired horn for EAW signature pattern control
- Lightweight and durable wooden enclosure with M10 threaded suspension points
Specifications:
Performance
- Max SPL: 138dB
- Operating range: 55 Hz to 20 kHz
- Nominal Beamwidth: 90° Horizontal and 60° Vertical, Constant Directivity, User Rotatable
Configuration
- LF Transducer, Loading: 15in Cone, Vented
- HF Transducer, Loading: 1in Exit, 1.7in voice coil compression driver, Horn Loaded
- Operating Mode: Bi-Amp LF, HF
- Signal processing: DSP w/EAW Focusing and DynO
- Modes: Main / Monitor, HPF Select
Electrical performance
- Input: Electronically Balanced XLR / TRS
- Loop: Electronically Balanced XLR
- Amplifier:
- Type Class – D
- Max Output LF/HF (Peak) – 1500W
- AC Mains (nominal):
- Connector – IEC Connector
- Input – 100-120V or 200-240V, 50-60Hz
This EAW RS151 15-Inch Self-Powered Subwoofer is perfect for various venues. It's great for Houses of Worship, Theatres, Auditoria, Performing Arts Centers, Live Music Clubs, Corporate AV Houses, Live Production/Regional Rental Houses, and Dry Hire. The lightweight and durable wooden enclosure makes it easy to use and move around. With a 15-inch size, it delivers powerful sound. It's designed for those who demand high-quality audio performance. The subwoofer has a max SPL of 138dB, an operating range from 55 Hz to 20 kHz, and a nominal beamwidth of 90° Horizontal and 60° Vertical with constant directivity and user rotatable features.
