EAW 2070185-90 AC6 2-Way Full Range ADAPTive Column - Black

EAW AC6 2-Way Full Range ADAPTive Column Speaker - Sleek Black

Discover the EAW AC6, a 2-way full-range ADAPTive column speaker that delivers outstanding sound quality. With Adaptive Performance technology, it offers exceptional coverage and directivity control. The Resolution 2 software ensures precise sound management. This robust speaker is perfect for both indoor and outdoor use with weather protection covers.

Features:

• • Adaptive Performance via Resolution 2 software for optimal coverage and directivity
• • Outdoor-ready with weather protection covers for versatile installation
• • EAW acoustical design and DSP for crystal-clear sound

Specifications:

• Max SPL (Peak 1m): 143 dB (unadapted)
• Operating Range: 65 Hz – 20 kHz (-10 dB)
• Nominal Beamwidth: 120° Horizontal x Adaptive Vertical
• LF Transducer: 6 x 6 in cone, 1.7 in voice coil vented
• HF Transducer: 30 x 19 mm dome tweeter, horn loaded
• Signal Processing: DSP with EAW Focusing and Adaptive Performance
• Max Input Level: 25 dBu
• Impedance: 20k Ohm (balanced)
• Power Draw: 600W
• Amplifier Type: Class D
• Amplifier Output: 6 x 150W LF, 30 x 75W HF
• Driver Protection: Integral DSP Limiting
• AC Mains Input: 100V to 240V, 50Hz to 60Hz
• Power Connector: Neutrik PowerCON True1 Top
• Power Consumption: Full: 600W

The EAW AC6 2-Way Full Range ADAPTive Column Speaker is a versatile audio solution suitable for a variety of settings. Whether you're setting up a concert, a corporate event, or an outdoor gathering, this speaker is designed to meet your needs. Its robust construction and weather protection make it ideal for both indoor and outdoor use. Key features include Adaptive Performance technology for excellent coverage and directivity, EAW acoustical design for clear sound, and integration with Dante redundant networking for reliable connectivity. With a max SPL of 143 dB (unadapted), an operating range of 65 Hz – 20 kHz (-10 dB), and a nominal beamwidth of 120° horizontal x Adaptive vertical, this speaker delivers powerful and precise sound. The LF transducer consists of 6 x 6 in cone with a 1.7 in voice coil vented, while the HF transducer is a 30 x 19 mm dome tweeter, horn loaded. It also offers on-board diagnostics for real-time monitoring and corrections.
