DiGiCo Quantum 225: The Ultimate Compact Digital Mixing Console
Get studio-quality mixes with ease using the DiGiCo Quantum 225! This compact digital mixer packs a punch with 72 input channels, 36 buses, and a 12-in/12-out processing matrix. With Mustard Processing channel strips and Spice Rack insert effects, you'll achieve professional-level sound in no time. • High-performance signal processing for studio-quality mixes • Intuitive control with a 17-inch multi-touch screen and 25 motorized faders • Customizable left work surface to fit your workflow Perfect for sound engineers, musicians, and producers, the DiGiCo Quantum 225 is a must-have for any audio setup. With its compact size and powerful features, you'll be able to create amazing mixes wherever you are. Searching for a digital mixer? Look no further than the DiGiCo Quantum 225! Mixing console, digital mixer, audio equipment
Features:
- 72 input channels, 36 buses, an LR/LCR master bus, and a 12-in/12-out processing matrix
- Mustard Processing channel strips with emulated tube preamplification, EQ, and dynamics processing
- Spice Rack provides powerful FPGA-fueled insert effects
- Local connections include 8 analog inputs, 8 analog outputs, and 4 channels of AES digital I/O
- 2 redundant MADI ports deliver 4 channels of MADI I/O at 48kHz or 2 channels of MADI I/O at 96kHz
- Add a single loop of Optocore with 504 channels and 14 DiGiCo racks or dual loops for 1,008 channels and 28 racks
- UBMADI gives you 48 channels of computer recording and playback via USB
- 2 dedicated DMI slots make expansion a piece of cake (DMI interface option cards sold separately)
- 17-inch multi-touch screen with a meter bridge and soft quick-select buttons
- 41 innavidual TFT LCDs for displaying channel information and metering, bank information, macros, and more
- 25 touch-sensitive, motorized 100mm faders yield comfortable tactile control
- Customizable left work surface accommodates laptops, controllers, and screens
Specifications:
- Type: Digital Mixer
- Channels: 72
- Inputs - Mic Preamps: 8 x XLR
- Phantom Power: 72 Channels
- Inputs - Line: 8 x XLR
- Outputs - Main: 8 x XLR
- Inputs - Digital: 2 x XLR (AES/EBU)
- Outputs - Digital: 2 x XLR (AES/EBU)
- Busses/Groups: 36 Aux/Sub-Group busses with full processing
- Inserts: 24 Mustard processing strips (internal)
- MIDI I/O: In/Out/Thru, USB
- Data I/O: 4 x Ethernet
- Headphones: 1 x 1/4', 1 x 1/8'
- USB: 1 x Type B, 3 x Type A
- Computer Connectivity: USB, Ethernet
- I/O Expansion Slots: 2 x Slots Available
- Word Clock: In/Out
- Faders: 25 x 100mm touch-sensitive, motorized faders, 17' Multi-touch screen
- A/D Resolution: 24-bit/96kHz
- EQ Bands: 16 x 32-band Graphic EQ, 4-band with 2-band Parametric
- Effects: Yes, Delay, Chorus, Reverb, Pitch Shifter, Audio Enhancer
- Signal Processing: Compressor, Multiband Compressor, Gate, Duck
- Transport Controls: Yes
- Screen: 17' touchscreen
- Power Source: 2 x Standard IEC AC Cable
- Height: 17.1'
- Depth: 32.5'
- Width: 44.25'
- Weight: 94.8 lbs.
The DiGiCo Quantum 225 is a compact digital mixer designed for sound engineers, musicians, and producers. It features 72 input channels, 36 buses, and a 12-in/12-out processing matrix. With its intuitive control and customizable left work surface, it's perfect for any audio setup. The mixer measures 17.1' in height, 32.5' in depth, and 44.25' in width, weighing 94.8 lbs.
