DiGiCo DMI ST Optocore Single-Mode Optics Expansion Cards - Enhance Your Audio Setup
• Connect Optocore audio via HMA, OpticalCon, or ST connectors with the MOD-DMI-OP-STS card.
• Add the Orange Box to an Optocore loop for seamless integration.
• Control DiGiCo I/O through an SD console via a 4REA4.
The MOD-DMI-OP-STS card enables Optocore audio transmission over ST connectors. Connecting it to the DiGiCo OrangeBox (a simple format converter) allows the OrangeBox to be incorporated into an Optocore loop and interfaced with another DMI card, providing up to 128 channels of I/O at 48kHz or up to 64 channels of I/O at 96kHz. It can also be used in a 4REA4, enabling an SD console to control I/O connected to the 4REA4. This card is compatible with the Orange Box and the 4REA4, and supports fibre speeds of 1G or 2G.
Features:
- Available with HMA (MOD-DMI-OPTO,) OpticalCon (MOD-DMI-OP-NCS,) or ST (MOD-DMI-OP-STS) connectors
- Available in MultiMode or SingleMode
- Allows an Orange Box to be added to an Optocore loop
- Up to 128 channels of I/O at 48kHz
- Up to 64 channels of I/O at 96kHz
- Allows DiGiCo I/O to be controlled via an SD console through a 4REA4
- Supports fibre speeds of 1G or 2G
- Compatible with Orange Box and 4REA4
These expansion cards are designed for audio professionals who want to enhance their audio setup. They can be used in various scenarios such as in a live sound system or a recording studio. Connect Optocore audio via different connectors like HMA, OpticalCon, or ST. Add the Orange Box to an Optocore loop for seamless integration. Control DiGiCo I/O through an SD console via a 4REA4. Technical specs include support for fibre speeds of 1G or 2G, compatibility with Orange Box and 4REA4, and available in different modes.
