Blackmagic DeckLink 4K Extreme 12G HDMI 2.0 Card

This amazing card is a game-changer for video professionals! It offers incredible features that will take your work to the next level. • High-Resolution Capture & Playback: Record and play back videos in stunning 4K resolution at 60 fps. • Versatile Inputs & Outputs: Supports multiple video formats and connectors, including 12G-SDI, HDMI 2.0b, and more. • Color Precision: Delivers accurate 10-bit YUV and 8-, 10-, and 12-bit RGB color.

Specifications:

• Host Connection: PCIe x8 ()
• Input:
  • Video Input Connectors:
    • 2 x BNC (12G-SDI)
    • 1 x HDMI (HDMI 2.0b)
    • 1 x 3BNC (Component / Composite / S-Video)
  • Input Video Format:
    • SDI / Component / Composite (8/10/12-Bit 4:4:4/4:2:2):
      • DCI 4K: 23.98/24 fps
      • UHD 4K: 23.98/24/25/29.97/30/50/59.94/60 fps
      • DCI 2K: 23.98/24/25 fps
      • DCI 2KPsF: 23.98/24/25 fps
      • 1080p: 25/29.97/30/50/59.94/60 fps
      • 1080PsF: 23.98/24/25/29.97/30 fps
      • 1080i: 50/59.94/60 fps
      • 720p: 50/59.94/60 fps
      • 576i / 625 lines: 50 fps
      • 480i / 525 lines: 59.94 fps
    • HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0):
      • DCI 4K: 23.98/24 fps
      • UHD 4K: 23.98/24/25/29.97/30/50/59.94/60 fps
      • 1080p: 23.98/24/25/29.97/30/59.94/60 fps
      • 1080PsF: 23.98/24/25/29.97/30 fps
      • 1080i: 50/59.94/60 fps
      • 720p: 50/59.94/60 fps
      • 576i / 625 lines: 50 fps
      • 480i / 525 lines: 59.94 fps
    • Component:
      • 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
      • 1080PsF: 23.98/24/25/29.97/30 fps
      • 1080i: 50/59.94/60 fps
      • 576i / 625 lines: 50 fps
      • 480i / 525 lines: 59.94 fps
    • Composite:
      • PAL
      • NTSC
  • Simultaneous Multi-Input Support: Yes: 2 Simultaneous Inputs
  • Audio Input Connectors: None
  • Input Audio Format: AES/EBU
  • Embedded Audio Input:
    • SDI: 16-Channel
    • HDMI: 8-Channel
• Output:
  • Video Output Connectors
    • 2 x BNC (12G-SDI)
    • 1 x HDMI (HDMI 2.0b)
    • 1 x 3BNC (Component / Composite / S-Video)
  • Output Video Format:
    • SDI (8/10/12-Bit 4:4:4/4:2:2):
      • DCI 4K: 23.98/24/25 fps
      • UHD 4K: 23.98/24/25/29.97/30/50/59.94/60 fps
      • DCI 2K: 23.98/24/25 fps
      • DCI 2KPsF: 23.98/24/25 fps
      • 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
      • 1080PsF: 23.98/24/25/29.97/30 fps
      • 1080i: 50/59.94/60 fps
      • 720p: 50/59.94/60 fps
      • 576i / 625 lines: 50 fps
      • 480i / 525 lines: 59.94 fps
    • HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0):
      • DCI 4K: 23.98/24/25 fps
      • UHD 4K: 23.98/24/25/29.97/30/50/59.94/60 fps
      • 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
      • 1080PsF: 23.98/24/25/29.97/30 fps
      • 1080i: 50/59.94/60 fps
      • 720p: 50/59.94/60 fps
      • 576i / 625 lines: 50 fps
      • 480i / 525 lines: 59.94 fps
    • Component / Composite:
      • NTSC: 59.94 fps
      • PAL (768 x 576): 50 fps
  • Output Audio Format: AES/EBU
  • Embedded Audio Output:
    • SDI: 16-Channel
    • HDMI: 8-Channel
• Standards:
  • Video Standard Compliance:
    • SMPTE 259M/292M/296M/372M/425M/435/2108-1/ST-2081/ST-2082/ST-2082-10
    • ITU -R BT.601/BT.656
  • HDR Compatibility: Hybrid Log Gamma
• Hardware:
  • OS Compatibility:
    • macOS 10.15
    • macOS 11.1 or Later
    • Linux
    • Windows 8.1
    • Windows 10
  • Power Consumption: Device: 30 W
• Environmental:
  • Operating Temperature: 41 to 104°F / 5 to 40°C
  • Storage Temperature: -4 to 113°F / -20 to 45°C
  • Operating Humidity: 0 to 90%
• General:
  • Dimensions: 6.69' / 169.93 mm
  • Weight: 0.66 lbs. / 299 g
• Packaging Info:
  • Package Weight: 1.9 lbs.
  • Box Dimensions (LxWxH): 8.85 x 6.1 x 3.15'

This Blackmagic DeckLink 4K Extreme 12G HDMI 2.0 Card is perfect for video professionals who need high-quality capture and playback capabilities. With its 8-lane PCIe Gen2 interface, it can handle resolutions up to DCI 4K at 60 fps. It's suitable for use in a variety of video production scenarios, such as live events, studio recordings, and post-production work. The card measures 6.69' (169.93 mm) and weighs 0.66 lbs. (299 g). It's compatible with macOS 10.15 and later, Linux, Windows 8.1, and Windows 10.
