D&B E8 8-Inch Passive Loudspeaker - High-Performance Sound
The E8 is an amazing high-performance 2-way multipurpose loudspeaker! • It features an integrated coaxial driver for outstanding sound quality. • Use it for speech and music applications, either as a stand-alone full range system or in larger distributed sound setups. • Pair it with an E12X subwoofer (passive or active) or other E-Series subwoofers to reproduce high-level music. The enclosure's multifaceted shape allows upright, horizontal use, or as a stage monitor. The horn's 90° x 50° dispersion pattern can be rotated 90° for a 50° x 90° pattern. The cabinet is made of polyurethane integral hard foam with an impact-resistant paint finish, a handle, and a socket for speaker stands. Special Color (SC) and Weather Resistant (WR) options are available. The WR option has an IP54 rating for use in changing conditions. Both come with colored metal plates for handle recesses and speaker stand sockets.
Features:
- Components: 8″/1″
- Dispersion: 90° x 50° rotatable
- SPLmax: 129 dB
- Weight: 7.3 kg / 16.1 lb
Specifications:
- System data:
- Frequency response (-5 dB standard): 62 Hz - 18 kHz
- Frequency response (-5 dB CUT mode): 120 Hz - 18 kHz
- Max. sound pressure:
- with 10D: 126 dB
- with D20/5D/30D: 129 dB
- with D40/D80/40D: 129 dB
- Cabinets per amplifier channel: 3
- Loudspeaker data:
- Configuration: 2-way compact coaxial loudspeaker
- Nominal impedance: 12 Ω
- Power handling capacity (RMS/peak 10 ms): 150/800 W
- Nominal dispersion angle (h x v): 90° x 50° rotatable through 50° x 90°
- Components:
- 8' driver with neodymium magnet
- 1' exit compression driver with 1.75' coil and rotatable CD horn
- passive crossover network
- Connections: 2 x NL4
- Dimensions / weight:
- Dimensions (H x W x D): 390 x 232 x 223 mm / 15.4 x 9.1 x 8.8'
- Weight: 7.3 kg / 16.1 lb
The D&B E8 8-Inch Passive Loudspeaker is a versatile audio solution. Ideal for event organizers, musicians, and sound engineers. • Use it for live performances, conferences, and installations. • Its compact size (390 x 232 x 223 mm) and lightweight (7.3 kg) make it easy to set up and transport. • With its high-performance components and adjustable dispersion, it delivers excellent sound quality in any setting.
