Avid E6L144 8U Engine for S6L Console - The Ultimate Mixing Powerhouse
Revolutionize your mixing experience with the Avid VENUE E6L! This state-of-the-art real-time processing engine offers maximum stability and power, handling all routing, channel, and mixing functions with ease. The HDX-powered DSP engine manages AAX plug-in processing with full automatic delay compensation, ensuring seamless performance.
Key Features:
- • Create Bigger, Better Sounding Mixes: With hundreds of processing channels and mix busses, you can take your mixes to the next level.
- • Enjoy Tight, Robust Plug-in Performance: Experience the best in plug-in performance with no round trips to external servers.
- • Lowest Possible Latency: Say goodbye to latency and hello to crystal-clear audio.
Specifications:
- Sample Rates: 48/96 kHz
- Input Channels: 144
- Input Processing: True Gain compensation, HPF, LPF, 4-band PEQ, Expander/Gate, Compressor/Limiter, Delay, 4 plug-in inserts, hardware insert
- Mix Busses: 64 + LCR
- Output Processing: 7-band PEQ, Compressor/Limiter, Delay, 4 plug-in inserts, hardware insert
- Matrix: 16 x 16
- VCAs: 24
- Stereo Solo Busses: 2, with independent control
- Graphic EQs (31-band): 32
- Plug-inn Support: HDX-powered, 64-bit AAX DSPplug-ins via expansion slots
- Plug-in Slots: 128
- Pro Tools Integration: Record/play back up to 64 audio tracks via Ethernet ABB, Higher track counts with Thunderbolt Option Card, Ethernet AVB Ports: 2 per Ethernet AVB card; selectable as etherCON (copper) or SFP (fiber), with redundant ring topology, Engine can be expanded with up to three Ethernet AVB cards
- Word Clock I/O: BNC, 75 Ohm coaxial
- USB Ports: 5 USB 2.0 ports (2 front; 2 back, 1 internal)
- Option Card Slots: 1 PCI Express (PCIs)
- Power Supply: N+1 redundant, internal hot-swappable PSUs
- Dimensions (H x W x D): 8.6 x 16.9 x 19 inches (216 x430 x 483 mm)
- Rack Spaces: 5U
- Weight: 61 lbs (28kg)
The Avid E6L144 8U Engine for S6L Console is designed for professional audio engineers and music producers. It's perfect for creating high-quality mixes in recording studios, live sound events, and broadcast applications. With its powerful processing capabilities and extensive I/O options, you can handle complex audio setups with ease. The engine has a compact size of 8.6 x 16.9 x 19 inches (216 x430 x 483 mm) and weighs 61 lbs (28kg), making it suitable for installation in standard 5U rack spaces.
