Audio Technica ATW 3211N 3000 Wireless Network Transmitter & Receiver

Audio Technica ATW 3211N 3000 Wireless Transmitter & Receiver 530 - 590 MHZ (No Mic)

The 3000 Series network-enabled systems bring you the same great features and configurations as the standard systems, plus network monitoring and control via Audio-Technica's Wireless Manager software. Each network-enabled receiver also comes with an AT8631 joining plate.

Check out the ATW-R3210N network-enabled receiver and ATW-T3201 body-pack transmitter with cH-style screw-down 4-pin connector.

Features:

• • Ultra-wide 60 MHz UHF tuning bandwidth for maximum flexibility in a crowded RF environment; available in EE1 (530–590 MHz) and DE2 (470–530 MHz). Perfect for event organizers and broadcasters!
• • Unique multifunction button on transmitters allows you to easily switch to a backup frequency in case of interference. Keep your signal strong!
• • Network-enabled system with the ATW-R3210N receiver offers network monitoring and control via Wireless Manager software. Ideal for professionals who need remote management.
• • True Diversity operation reduces dropouts, ensuring a stable signal. Great for live performances!
• • Auto Squelch feature automatically adjusts squelch setting for maximum range with minimal interference. Enjoy clear audio everywhere!
• • Frequency scan and IR sync functionality for easy setup. Save time and hassle!
• • Dual-mode receiver display can switch between standard and performance views. Stay informed about key metering.
• • Transmitters and receivers have OLED screens for clear readout of key settings and alerts. Never miss a thing!
• • Handheld transmitter has extremely low handling noise and an industry-standard thread mount for six interchangeable A-T microphone capsules. Great for presenters!
• • New rugged cH-style connector on body-pack transmitter provides a secure connection to lavalier mics, headworn mics, and cables. Reliable for on-the-go use!
• • Body-pack transmitter features a tactile mute toggle switch (defeatable) for physical confirmation of mute status. Convenient when the display is not visible.
• • Charging terminals on transmitters work with optional smart charging docks to recharge NiMH batteries. Always be ready!
• • Antenna power available for powered antennas and other in-line RF devices. Enhance your setup!
• • Ground-lift switch helps eliminate audible hum caused by ground loops. Enjoy noise-free audio!
• • Balanced and unbalanced audio output jacks for versatile connectivity.

Specifications:

• Operating Frequencies: Band EE1: 530.000 to 589.975 MHz (2400 frequencies)
• Minimum Frequency Step: 25 kHz
• Modulation Mode: FM
• Maximum Deviation:
  • ATW-T3201: ±38 kHz (THD:10%)
  • ATW-T3202: ±36 kHz (THD:10%)
• Dynamic Range:
  • ATW-T3201 Mic input: > 115 dB (A-weighted), typical
  • ATW-T3201 Inst input: > 112dB (A-weighted), typical
  • ATW-T3202: > 115 dB (A-weighted), typical
• Total Harmonic Distortion: <1.0% (at 1 kHz, ±17.5 kHz deviation)
• Operating Range: 100 m (328') Open range environment with no interfering signals.
• Operating Temperature Range: -5° C to +45° C (23° F to 113° F)

This Audio Technica ATW 3211N 3000 Wireless Network Transmitter & Receiver is perfect for event organizers, broadcasters, presenters, and anyone who needs a reliable wireless audio solution. With its wide range of features and great specifications, it can handle various audio needs. It operates within the frequency range of 530.000 to 589.975 MHz in Band EE1. The minimum frequency step is 25 kHz and it uses FM modulation mode. It has a maximum deviation of ±38 kHz (THD:10%) for ATW-T3201 and ±36 kHz (THD:10%) for ATW-T3202. The dynamic range is quite impressive with ATW-T3201 Mic input > 115 dB (A-weighted), typical, ATW-T3201 Inst input > 112dB (A-weighted), typical, and ATW-T3202 > 115 dB (A-weighted), typical. Total Harmonic Distortion is <1.0% (at 1 kHz, ±17.5 kHz deviation). In an open range environment with no interfering signals, it has an operating range of 100 m (328'). It can operate in temperatures from -5° C to +45° C (23° F to 113° F).
