Shure ULXD4D Dual-Channel Digital Wireless Receiver - X52 Band
Be part of the ULX-D wireless series! The Shure ULXD4D offers 2 independent digital receivers in a rugged, single-rack unit with an internal power supply. It's a must-have for large venues and A/V installations. • Dual-channel digital receivers for powerful audio. • Expandable up to 60 channels for flexibility. • Secure AES-256 encryption for peace of mind.
Features:
- Perfect for Large Venues & A/V Installations
- 2 x Digital Audio Channels, 1 Rackspace
- 64 MHz Tuning Range
- Expandable up to 60 Channels
- 2 x Ethernet/Dante Ports
- 2 x RF Cascade Ports
- Audio Summing
- Secure AES-256 Encryption
Specifications:
- Number of RF Channel Frequencies: 1040
- Diversity: Antenna Diversity
- RF Frequency Band: X52 (902 to 928 MHz)
- RF Bandwidth: 26 MHz
- Frequency Step Size: 25 kHz
- Max Operating Range: 328.1' / 100 m
- Max Transmitters per Band: 60
- Latency: < 2.9 ms
- Modulation: Proprietary
- Receiver:
- Receiver Type: Tabletop
- Mounting Options: Rackmount (with Included Hardware)
- Rackmount Size: 1 RU (1/2 Rack)
- Antenna: 2 x 1/2 Wave External, BNC (Rear-Mount)
- Antenna Bias Voltage: 12 to 13 VDC, 150 mA (per Antenna)
- Number of Audio Channels: 2
- Audio I/O: 2 x XLR 3-Pin Male Balanced Output
- Gain Range: -18 to +42 dB (1 dB Steps)
- Pad: 30 dB
- Audio Output Level:
- XLR Outputs: +18 dBV (Line Level, Balanced)
- XLR Output: -12 dBV (Mic Level)
- Phantom Power Protection: On XLR Outputs
- Frequency Response: 30 Hz to 20 kHz ±1 dB (Dependent on Mic)
- Network I/O: 2 x RJ45 (1 Gb/s)
- Network Protocols: DHCP, Dante, Manual IP
- Impedance: XLR Output: 100 Ohms (Balanced)
- Approximate RF Sensitivity: -98 dBm
- Adjacent Channel Isolation: >70 dB
- Spurious: Rejection (>80 dB)
- Power Requirements: AC Input
- AC Input Power: 100 to 240 VAC, 50 / 60 Hz at 0.32 A
- Display & Indicators:
- 1 x Backlit LCD (Battery Status, Channel, Group, Menu Navigation)
- 2 x Multi-Segment LED (AF Level, Output Level, Peak)
- Housing: Steel
- Operating Temperature: 0 to 122°F / -17 to 50°C
- Storage Temperature: -20 to 165°F / -28 to 73°C
- Dimensions: 19 x 1.7 x 10.8' / 482 x 44 x 274 mm
- Weight: 7.4 lb / 3.4 kg
- Packaging Info:
- Package Weight: 11.95 lb
- Box Dimensions (LxWxH): 27.5 x 17.5 x 3'
This Shure ULXD4D Dual-Channel Digital Wireless Receiver is perfect for large venues and A/V installations. It has 2 digital audio channels in a 1-rackspace unit. With a 64 MHz tuning range, it can expand up to 60 channels. The receiver has a steel housing, weighs 7.4 lb (3.4 kg), and measures 19 x 1.7 x 10.8' (482 x 44 x 274 mm). It operates from 0 to 122°F (-17 to 50°C) and stores from -20 to 165°F (-28 to 73°C).
