Shure Axient ADX5DUS Digital Dual-Channel Portable Wireless Receiver - C Band - Superior Performance for Your Audio Needs
Get superior RF performance, spectral efficiency, and transparent audio quality with the Axient Digital ADX5D dual-channel wireless receiver. It's portable and slot-in, so you can take it anywhere. With ShowLink Direct Mode, control Axient Digital transmitters without external equipment.* Experience robust RF, impeccable audio, and Axient Digital quality and performance in one sleek design.
Features:
- • Dual-channel slot-in form for easy portability
- • Wide tuning range up to 184 MHz (region dependent) for flexibility
- • High spectral efficiency with advanced digital modulation for more channels
- • True digital diversity reception per channel for reliable signal
- • Impeccable audio quality for a great listening experience
- • Networked control with Wireless Workbench software and ShurePlus Channels iOS app for easy management
- • 5-segment Channel Quality meters to monitor RF link quality
- • ShowLink Direct Mode for remote control of transmitters
- • Aux 3.5mm audio output for connecting headphones or line level input
- • Three backplate connector options (sold separately) for various applications
- • Accessory Mount with cold shoe adapter (sold separately) for added functionality
- • Removable antennas with standard SMA connectors for easy setup
- • High-resolution OLED display for clear information
- • USB-C port for firmware upgrades
- • Streamlined user interface for simplicity
- • Low latency, down to 2 milliseconds for real-time audio
Specifications:
- UHF:
- Frequency Band: 925–960 MHz
- Working Range:
- SD Mode: 246 ft (75 m)
- HD Mode: 131 ft (40 m)
- RF Sensitivity -90 dBm @ 105 BER
- Spurious Rejection: >80 dB
- Connector Type: SMA (Shell=Ground, Center=Signal)
- Impedance: 50 Ω
- Audio Output:
- Gain Adjustment Range: -18 to +42 dB, in 1 dB steps
- Impedance: 66 Ω
- Full Scale Output: +9 dBV, 200 kΩ load
- Phantom Power Protection: Yes, 3.5 mm output does not have Phantom Power Protection
- Audio Frequency Response: 20 Hz to 20 kHz
- Dynamic Range: 129 dB
- Total Harmonic Distortion: 0.0006% at -6 dBFS, 1 kHz
- System Audio Polarity: Positive pressure on diaphragm produces positive voltage on Audio + with respect to Audio -
- Analog Output Latency:
- SD Mode: 2.08 ms
- HD Mode: 2.96 ms
- USB Input:
- Connector Type: USB-C
- USB Protocol: USB 2.0
- USB Role: Peripheral (upstream-facing port)
- USB Power Delivery: None
- Power:
- DC Power Requirements: 6 to 18 VDC
- Thermal Power Dissipation:
- Max: 4.8 W (78 BTU/hr)
- Nominal: 4.2 W (51 BTU/hr)
- MIn: 2.3 W (X BTU/hr)
- Mechanical:
- Dimensions (H ¡Á W ¡Á D): 1.1 ¡Á 3.4 ¡Á 4.25 in (29 ¡Á 88 ¡Á 108 mm)
- Weight: 0.53 lbs (0.24 kg)
- Housing: Machined Aluminum
- SHOWLINK :
- Frequency Range: 2.40 to 2.4835 GHz (16 Channels)
- Working Range: 100 ft (30 m)
- Connector Type: SMA (Shell=Ground, Center=Signal)
- Impedance: 50 Ω
- ShowLink Antenna Power: 2.5 dBm EIRP
- Antenna Type: 1 Omni 2.4 GHz
- Network Type: IEEE 801.15.4
This Shure Axient ADX5DUS Digital Dual-Channel Portable Wireless Receiver is perfect for audio professionals on the go. Whether you're at a live event or recording in the studio, it delivers superior performance. With its dual-channel slot-in form, it's easy to carry around. It has a wide tuning range up to 184 MHz (region dependent). The dimensions are 1.1 x 3.4 x 4.25 in (29 x 88 x 108 mm) and it weighs 0.53 lbs (0.24 kg). It's housed in machined aluminum for durability.
