L-Acoustics L2DRAL 16 Channel PULS Active Speaker - The Ultimate in Sound Quality and Performance
The L-Acoustics L2DRAL is a game-changer in the world of professional audio. With its progressive curvature design and 60-degree enclosure, it delivers broad and even sound dispersion like never before. Whether you're in a large venue or a small club, this speaker is the perfect choice for all your audio needs.
Features:
- • Compact size with large-format system performance
- • Line source technology perfected with PULS
- • Best in class SPL/m, SPL/kg, SPL/m2
Specifications:
- • Usable bandwidth (-10 dB): 45 Hz – 20 kHz (L2 70)
- • Maximum SPL1:
- Full element: 151 dB (L2 70)
- First module: 147 dB (L2 70)
- • Nominal directivity (-6 dB):
- Vertical: 60° progressive directivity
- Horizontal:
- Top two modules: Panflex 70° / 90° / 110°
- Bottom two modules: progressive from 110° to 140°
- Integrated cardioid
- • Transducers:
- LC: 4 ¡Á 12'' neodymium cone drivers
- LF: 8 ¡Á 10'' neodymium cone drivers
- HF: 8 ¡Á 3'' neodymium compression drivers
- • Acoustical load:
- LC/LF: Bass-reflex, L-Vents
- HF: DOSC waveguide, Panflex
- • Nominal impedance:
- • Connectors: 1 x 37-point male connector (32 points used)
- • Rigging and handling: Flush-fitting 4-point captive rigging system compatible with L2D
- • Weight (net): 149 kg / 328 lb
- • Cabinet: Premium grade Baltic birch plywood
- • Front:
- Coated steel grill
- acoustically neutral 3D fabric
- • Rigging components: High grade steel with anti-corrosion coating
- • IP: IP55
The L-Acoustics L2DRAL 16 Channel PULS Active Speaker is perfect for professional audio applications. It's great for large venues like concert halls or small clubs. This speaker has a progressive curvature design and a 60-degree enclosure for broad sound dispersion. It has a compact size with large-format system performance, line source technology perfected with PULS, and best-in-class SPL/m, SPL/kg, SPL/m2. The usable bandwidth (-10 dB) is 45 Hz – 20 kHz (L2 70). Maximum SPL1 is 151 dB for the full element and 147 dB for the first module (L2 70). Nominal directivity (-6 dB) has a 60° progressive vertical directivity and specific horizontal directivities for different module combinations. It has multiple transducers and specific acoustical load setups. The nominal impedance is 8 for different components. It has a 1 x 37-point male connector (32 points used), a flush-fitting 4-point captive rigging system compatible with L2D, weighs 149 kg / 328 lb, has a cabinet of premium grade Baltic birch plywood, a coated steel grill and acoustically neutral 3D fabric at the front, high grade steel rigging components with anti-corrosion coating, and an IP55 rating.
