Electro-Voice EKX-12 Passive 12-in PA Speaker

Electro-Voice EKX-12: The Ultimate 12-inch PA Speaker for Unbeatable Sound

Features:

• • Powerful Performance: Delivers 1400 W (peak) and 131 dB peak SPL with high-sensitivity transducers.
• • Precise Coverage: EV-patented SST waveguide design ensures consistent and accurate sound projection.
• • Durable & Compact: Lightweight 15-mm wood enclosure with internal bracing and EVCoat finish.

Specifications:

• Axial Sensitivity (SPL, 1 W @ 1 m): 95 dB
• Connector Type: Dual NL4
• Coverage (Nominal -6 dB) H: 90°
• Crossover Frequency: 1.6 k Hz
• Enclosure Material: 15 mm, plywood with EVCoat
• Frequency Response (-10 dB): 55 Hz - 20 k Hz Full Space Measurement
• Frequency Response (-3 dB): 82 Hz - 18 k Hz Full Space Measurement
• Grill: 18 AWG steel with powdercoat
• HF Transducer: DH-1M 1-inch titanium compression driver
• LF Transducer: EVS-12M 300 mm (12 in)
• Maximum SPL: 131 dB Maximum SPL is measured at 1 m using broadband pink noise at rated peak power rating
• Minimum Impedance: 7.5 Ohm
• Nominal Impedance: 8 Ohm
• Power Handling (Continuous/Peak): 350 W/1400 W
• Recommended High-Pass Frequency: 55 Hz
• Suspension: (8) M10 threaded mounting points
• Height: 14RU 607 mm (23.9')
• Width: 375 mm (14.76')
• Depth: 356 mm (14.02')
• Weight: 17.4 kg (38.36 lbs.)

The Electro-Voice EKX-12 is a top-notch 12-inch PA speaker perfect for mid-size stages. It's designed for musicians, DJs, and event organizers who want great sound. With its powerful performance, precise coverage, and durable build, it can handle various gigs. Measuring 14RU (607 mm) in height, 375 mm in width, and 356 mm in depth, and weighing 17.4 kg (38.36 lbs.), it's easy to set up and transport. Whether you're hosting a live band performance or a DJ set, the EKX-12 will deliver outstanding sound quality.
