D&B Audiotechnik Z1619.100 10S-D 10-Inch Passive Loudspeaker - Weather-Resistant

D&B Audiotechnik Z1619.100 10S-D Weather-Resistant 10-Inch Passive Loudspeaker

• High Performance: These biaxial loudspeakers deliver top-notch sound quality for an immersive audio experience.
• Weather-Resistant Design: With an IP55 rating, they can withstand various outdoor conditions, making them perfect for schools, sports halls, and other outdoor venues.
• Versatile Usage: Their frequency response from 60 Hz to 18 kHz allows them to be used as full range systems or paired with different subwoofers from the xS-Series.

The biaxial 10S/10S-D are high performance 2-way loudspeakers housing a single 10' driver in a bass-reflex enclosure and different HF sections. They are lightweight passive designs using neodymium drivers and large horns for accurate pattern control with rotatable dispersion characteristics of 75° x 50° and 110° x 55° respectively. With their frequency response from 60 Hz to 18 kHz both versions can be used as full range systems and can also be supplemented by different subwoofers from the xS-Series. The enclosures are constructed from marine plywood with an impact resistant black paint finish and are Ball Impact Resistant according to DIN 18032-3 for schools and sports halls. The front of the loudspeaker cabinet is protected by a rigid metal grill backed by an acoustically transparent foam. The top and bottom panels incorporate a pair of M10 threaded inserts, and the rear panel incorporates two M8 threaded inserts. The loudspeaker cabinets and most accessories are also available with the Special Colour (SC) option that can be executed in all RAL colours, whilst the Weather Resistant (WR) option provides an IP55 rating, and enables operation of loudspeakers in changing ambient conditions.

Cabinets with the weather resistant option (WR) are equipped with a fixed input cable (PG type, H07-RN-F, 2 x 2.5 mm2 (AWG 13), standard length 5.5 m (18 ft).

Features:

• Components 10'/1.4'
• Dispersion 110° x 55° rotatable
• SPLmax 130 dB
• Weight 13 kg / 29 lb

Specifications:

• System data:
  • Frequency response (-5 dB standard): 60 Hz - 18 kHzz
  • Frequency response (-5 dB CUT mode): 100 Hz - 18 kHz
  • Max. sound pressure:
    • with 10D: 127 dB
    • with D20/5D/30D: 130 dB
    • with D40/D80/40D: 130 dB
  • Cabinets per amplifier channel: 3
• Loudspeaker data:
  • Configuration: Installation-specific high-performance 2-way loudspeaker with wide dispersion
  • Nominal impedance: 12 Ω
  • Power handling capacity (RMS/peak 10 ms): 200/1200 W
  • Nominal dispersion angle (h x v): 75° x 50° rotatable
  • Components:
    • 10' driver with neodymium magnet
    • 1.4' compression driver with CD horn
    • Passive crossover network
  • Connections:
    • Faston connector type 2
• Dimensions / Weight:
  • Dimensions (H x W x D):
  • H: 22-13/16″ (638 mm)
  • W: 11-3/32″ (338 mm)
  • D: 13-13/16″ (365 mm)
  • Weight: 29 lb. (13 kg)

This D&B Audiotechnik Z1619.100 10S-D Weather-Resistant 10-Inch Passive Loudspeaker is perfect for outdoor venues like schools and sports halls. It has a frequency response from 60 Hz to 18 kHz, allowing for versatile use as a full range system or with subwoofers. The speaker features a 10-inch driver and 1.4-inch compression driver, with rotatable dispersion angles of 75° x 50° or 110° x 55°. It weighs 13 kg (29 lb) and has dimensions of 22-13/16″ (H) x 11-3/32″ (W) x 13-13/16″ (D).
