D&B Audiotechnik Z1618.100 10S 10-Inch Passive Loudspeaker - Weather-Resistant

D&B Audiotechnik Z1618.100 10S Weather-Resistant 10-Inch Passive Loudspeaker

• High-performance 2-way loudspeakers with a single 10' driver in a bass-reflex enclosure. Ideal for delivering great sound in various settings like schools and sports halls. • Lightweight passive design using neodymium drivers and large horns for accurate pattern control. With rotatable dispersion characteristics of 75° x 50° and 110° x 55°, it gives you flexibility. • Frequency response from 60 Hz to 18 kHz makes it suitable as a full range system and can be paired with different subwoofers from the xS-Series. The enclosures are made of marine plywood with a tough black paint finish and are impact resistant. The front is protected by a metal grill and foam. It also has M10 and M8 threaded inserts for easy installation. Available in special colours and with a Weather Resistant (WR) option for IP55 rating, allowing use in changing conditions. Cabinets with WR option come with a fixed input cable.

Features:

• Components 10'/1.4'
• Dispersion 75° x 50° rotatable
• SPLmax 130 dB
• Weight 13 kg / 29 lb

Specifications:

• System data:
  • Frequency response (-5 dB standard): 60 Hz - 18 kHzz
  • Frequency response (-5 dB CUT mode): 100 Hz - 18 kHz
  • Max. sound pressure:
    • with 10D: 127 dB
    • with D20/5D/30D: 130 dB
    • with D40/D80/40D: 130 dB
  • Cabinets per amplifier channel: 3
• Loudspeaker data:
  • Configuration: Installation specific high performance 2-way loudspeaker
  • Nominal impedance: 12 Ω
  • Power handling capacity (RMS/peak 10 ms): 200/1200 W
  • Nominal dispersion angle (h x v): 75° x 50° rotatable
  • Components:
    • 10' driver with neodymium magnet
    • 1.4' compression driver with CD horn
    • Passive crossover network
  • Connections:
    • Faston connector type 2
• Dimensions / Weight:
  • Dimensions (H x W x D): 580 x 283 x 350 mm / 22.8 x 11.1 x 13.8'
  • Weight: 13 kg / 129 lb

This weather-resistant 10-inch passive loudspeaker is perfect for places like schools and sports halls. It's lightweight and has great sound quality. The dimensions are 580 x 283 x 350 mm and it weighs 13 kg. It's designed for those who need reliable sound in different environments.
