D&B Audiotechnik Z0515.001 V8 Loudspeaker with NL4 Connections
• Exceptional Sound Quality: The V8 offers a 3-way passive design with smooth frequency band overlap, delivering outstanding audio performance. • Versatile Setup: It can be used in vertical arrays of up to twenty four loudspeakers, either alone or combined with V12s and V-SUBs. • Durable Construction: Built from marine plywood with PCP finish and protected grill, ensuring long-lasting use.
Specifications:
- System data:
- Frequency response (-5 dB standard): 67 Hz - 18 kHz
- Frequency response (-5 dB CUT mode): 100 Hz - 18 kHz
- Max. sound pressure:
- with D20/30D: 139 dB
- with D40/D80/40D: 142 dB
- Cabinets per amplifier channel: 2
- Loudspeaker data:
- Configuration: High performance 3-way passive line array loudspeaker
- Nominal impedance: 8 Ω
- Power handling capacity (RMS/peak 10 ms: )500/2000 W
- Nominal dispersion angle (horizontal): 80°2
- Splay angle settings: 0° - 14° (1° increment)
- Components:
- 2 x 10' driver / 1 x 8' driver
- 2 x 1.4' exit compression driver
- passive crossover network
- Connections: 2 x NL4
- Dimensions / weight:
- Dimensions (H x W x D): 310 x 700 x 460 mm (12.2 x 27.5 x 18')
- Weight: 34 kg (75 lb)
The D&B Audiotechnik Z0515.001 V8 loudspeaker is perfect for live events, concerts, and installations. Ideal for audio professionals and enthusiasts. With dimensions of 310 x 700 x 460 mm and weighing 34 kg, it offers great flexibility in setup.
